Sewage Corrugated Pipe Extrusion Line High Ring Stiffness SN8 SN20 3000mm

High Ring Stiffness Sewage/Drainage Corrugated Pipe Production Line

DN 300 - DN 3000

Stiffness SN 8, SN 12.5, SN 16

Pipe weight reduce 25-50%

Material cost reduce 30%

Compared with the traditional steel and concrete pipe, the plastic pipe has big advantages, such as anti-corrosive, less leakage, light weight and easy installation. But the serious disadvantage of the plastic pipe is the low elastic modulus, e.g. polyethylene Ep value is about 800 Mpa. This character makes the full plastic pipe can not provide a high ring stiffness easily. Or, even we can approach to the high ring stiffness by increasing the wall thickness and material grade, but the expensive pipe cost is not acceptable by most of end users. So before the developing of the reinforced structure wall pipe, the full plastic pipe is mainly used in the area of small and middle diameter ranges.

1) High ring stiffness

For normal buried sewage plastic structure wall pipe, its maximum ring stiffness is difficult to over SN 8. But in new pipe, stiffness can easily reach the surprisingly value of SN 8, SN 12.5 and SN 16, even higher if necessary. In other hand, thanks to plastic properties, the plastic-steel-plastic composite structure could against corrosion very well.

2) Saving Material Cost

Besides the enhanced performance, the other primary advantage is that the new pipe can save material cost obviously. When pipe diameter is over Dn1000, SRPCP can save the plastic materials consumption nearly in 50% when compared with other plastic sewage pipe in same stiffness.
